WOODWARD 8272-683 DIGITAL REFERENCE UNIT

WOODWARD MSLC-2 Master Synchroniz

DESCRIPTION

Woodward’s MSLC-2™ functions with the DSLC-2™ control to provide synchronization and load

control across Utility and Intertie breakers. The MSLC-2/DSLC-2 combination operates over an

Ethernet communication network to control simple or complex generator system applications. This

combination, 32 DSLC-2’s and 16 MSLC-2’s, provide multiple unit, multiple segment, utility and

intertie power management for complex power systems. Controls plant wide Import / Export levels

while always providing bump-less load transfers with utility.

The MSLC-2 control combines synchronization, dead bus closing, utility/intertie load sensor, baseload

control, import/export control, VAR, power factor, and a master process control in one powerful

package.

The MSLC-2 provides phase matching or slip frequency synchronization, with voltage matching,

across a utility or intertie breaker. The MSLC-2/DSLC-2 combination can handle multiple utility connections

with a maximum of 8 bus segments in one application.

The MSLC-2’s load sensor and load control sense true RMS power and provide a bump-less loading

and unloading against a utility grid. Baseload, import/export, process, and utility unload modes

control the KW power between different power sources at the same time controlling the reactive

power, VAR and power factor. Reactive power is also ramped on and off for the smoothest load

transactions between power grids.

The MSLC-2 communicates via Ethernet, with redundant Ethernet now available, to control real

and reactive loading against the utility by DSLC-2 equipped generators.

The tie breaker mode allows synchronization between multiple generator systems. Segments are

connected and power can be measured across an intertie, but no load control is functional when in

Tie breaker operation.

.FEATURES

 One MSLC-2 can provide master control for up to 32 DSLC and an additional 15 MSLC-2 in a system.

 Two dedicated Ethernet lines for precise system communications between all DSLC-2’s and

MSLC-2’s on the system.

 Ethernet Modbus TCP for remote control and monitoring by PLC or DCS system.

 Redundant Ethernet communications for enhanced reliability.

 Master MSLC-2 redundancy, loss of communications with the designated MSLC-2 master initiates control

hand off to the next designated MSLC-2 master.

 The MSLC-2 hardware is adjustable for multiple applications.

 Slip frequency or voltage phase matching synchronizing fully selectable with dead bus option in both directions

provide full flexibility for intertie and main-tie-main applications.

 Having functions integrated into one box eliminates the need for redundant sensors (like PTs, CTs, and

MOPs) that connect to individual modules such as the load sensor and synchronizer.

 Digital signal processing makes the MSLC-2 resistant to power line distortions and harmonics.

 Three-phase true RMS power sensing provides accurate readings even with unbalanced phase loading and

voltage fluctuations.

 Export/import control over multiple utility MSLC-2’s in same segment.

 The Woodward ToolKit™ software allows flexible setup using the same basic menu tree as the original MSLC

plus an overview screen. No hand held programmer is required. Graphical overview of generators and bus

bar parameters with trending makes the MSLC-2 commissioning friendly.

 The Toolkit can be accessed either via one of the Ethernet ports or via RS-232 port.

 Phase angle compensation provides adjustment for additional deviation correction across a transformer.

 The system update feature allows for system reconfiguration.
