MOTOROLA MVME187 RISC Single Board Computer Installation Guide
This manual provides a general board level hardware description, hardware
preparation and installation instructions, debugger general information, and
information about using the debugger.
This manual applies to the following MVME187 RISC Single Board Computers:
MVME187-001B 25MHZ, 4MB Parity
MVME187-002B 25MHZ, 8MB Parity
MVME187-003B 25MHZ, 16MB Parity
MVME187-004B 25MHZ, 32MB Parity
MVME187-023B 33MHZ, 16MB ECC, 128
MVME187-024B 33MHZ, 32MB ECC, 128C
MVME187-031B 33MHZ, 4MB ECC
MVME187-032B 33MHZ, 8MB ECC
MVME187-033B 33MHZ, 16MB ECC
MVME187-034B 33MHZ, 32MB ECC
MVME187-035B 33MHZ, 64MB ECC
MVME187-036B 33MHZ, 128MB ECC
The MVME187 ships with a start-up installation guide
(MVME187IG/D, the document you are presently reading) which
includes installation instructions, jumper configuration
information, memory maps, debugger/monitor commands, and
any other information needed for start-up of the board.
If you wish to develop your own applications or need more detailed
information about your MVME187 Single Board Computer, you
may purchase the additional documentation (listed on the
following pages) through your local Motorola sales office.
If any supplements have been issued for a manual or guide, they
will be furnished along with the particular document. Each
Motorola Computer Group manual publication number is suffixed
with characters which represent the revision level of the document,
such as “/D2” (the second revision of a manual); a supplement
bears the same number as a manual but has a suffix such as
“/D2A1” (the first supplement to the second edition of the
manual)
