FOXBORO Model H90 Workstation Server

FOXBORO Model H90 Workstation Server

As a multipurpose server running the Windows Server 2016 operating system, the Model H90 server supports hosting Foxboro Evo™ Control Core Services (Control Core Services) or Foxboro Evo Control Software (the Control Software) workstations, data acquisition and processing related to a broad range of applications, file serving capabilities, and the display of graphics and text. It also interfaces with corporate communication networks. These servers support a USB mouse or optional USB trackball, an optional USB speaker set, an alphanumeric keyboard, up to four USB annunciator keyboards or annunciator/numeric keyboards, plus up to four video monitors. The H90 server also supports multiple, optional USB touchscreens. These servers have an Intel Xeon® processor that can be configured with up to 2.4 TB of internal hard disk storage and up to 96 GB of ECC DDR-4 SDRAM Registered Memory. The Serial Attached SCSI (SAS) supports a system disk, expansion disks, or RAID1 or RAID5 hard drive arrays. Client/server communications are accomplished using the TCP/IP networking protocol

The Model H90 server contains the following elements:

 Intel Xeon E5-2609v3 Processor

 Pre-configured and installed Microsoft® Windows Server® 2016 operating system, 64-bit package

 Latest version of Veritas System Recovery 16 Software  8 GB DDR-4 Registered Memory

  One internal 300 GB hard drive

  Internal SATA CD-RW/DVD drive

 Dual DisplayPort/DVI PCIe card graphics generator, up to 1600 x 1200 pixel resolution

 4 Integrated 10/100/1000BaseT Ethernet ports

 Mouse (USB)  Keyboard (USB)  One serial interface port for customer supplied serial devices

 Redundant hot swappable power supplies

Redundant hot swappable fans

 Two rear USB ports and VGA analog video port

 Three front USB ports and VGA analog video port

 Mounting rail kit

Model H90 Options The Model H90 server offers the following options:

 Expandable to 96 GB of system RAM  Expandable to eight 300-GB hard drives

  Monitors with optional USB touchscreen(1)  Trackball  Ethernet adapter cards (copper or fiber)

 Dual/quad monitor graphics cards (dual is analog/digital; quad analog only)

 RAID1 or RAID5 internal hard drive arrays with optional hot spare drives

 Up to four USB annunciator keyboards

 Printers

 A Human Interface up to 150 m (492 ft) extension unit (RGU) servicing the following devices:

• Up to four video monitors

• Up to five USB devices
